Especificaciones

    Processor / System Bus
    2 x Socket P (LGA 3647)
    1st and 2nd Gen Xeon® Scalable Processor Family (150W)

    Core Logic
    Intel® PCH C621

    Memory
    Total Slots :
    16 (8-channel, 1DPC)
    Capacity :
    Max. 2,048GB
    Memory Type :
    DDR4 2933 RDIMM / LRDIMM / LRDIMM 3DS
    Memory Size :
    128GB, 64GB, 32GB, 16GB
    * Refer to support page for more information

    Expansion Slots
    Front :
    1 x PCIe x8 slot (Gen3 x8 link,LP,HL) for RAID/HBA card
    Rear :
    8 x PCIe x16 slots (Gen3 x16 link,FH,FL) for dual-slot GPU cards
    1 x PCIe x16 slot (Gen3 x16 link, LP, HL)
    1 x PCIe x8 slot (Gen3 x8 link, LP, HL)

    Storage
    Storage Controller :
    Intel® PCH C621
    Optional kits Controller :
    ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
    ASUS PIKE II 3108-8i 8-port SAS 12G RAID card

    Drive Bays
    8 x 3.5" Hot-swap Storage Bays (Backplane Supports 6 x SATA/SAS + 2 x SATA/SAS/NVMe Devices)*
    1 x M.2 socket (SATA or Gen3 x4 link, up to 2280 module)

    Networking
    2 x 1GbE LAN ports (RJ45, Intel I350-AM2)

    Multi-GPU Support
    Please find the latest GPU support from
    https://servers.asus.com/support/GPU

    Front I/O Ports
    2 x USB 3.2 Gen1 ports
    2 x USB 2.0 ports

    Rear I/O Ports
    2 x USB 3.2 Gen1 ports
    1 x VGA port
    2 x 1GbE LAN ports (RJ45)
    1 x Management port (RJ45)

    Switch/LED
    Front :
    1 x Power Button/LED
    1 x Location Button/LED
    2 x LAN LED
    1 x Message LED
    1 x HDD Access LED
    Rear :
    1 x Power Button/LED
    1 x Location LED
    1 x Message LED
    1 x HDD Access LED

    Dimensions
    800 x 440 x 88mm

    Form Factor
    2U

    Weight
    Net Weight: 34 Kg.
    Gross Weight: 44 Kg.

    Power Supply
    1+1 Redundant 1600W 80 PLUS Platinum Power Supply
    Rating: 100-127Vac/200-240Vac,12.9A/9.5A, 47-63Hz
    1+1 Redundant 2200W 80 PLUS Platinum Power Supply Rating: 100-127Vac/200-240Vac,14A/12.6A, 47-63Hz

    Environment
    Operation temperature: 10 ~ 35
    Non operation temperature: -40 ~ 70
    Non operation humidity: 20% ~ 90% ( Non condensing)

    Note
    *The front 2 x NVMe signal is shared with the front PCIe slot (Gen3 x8 link).
